UV Flatbed Printer 2513 with EPSON i3200
DG-2513 with a large format printing size 2.5mX1.3m,allow large quantity production.It is automatic so that easy to learn and operate.print head base board is OEM by professional factory,high-precision process.Equipped with EPSON i3200 print head,which has a high print speed.3.8pl ink drop size,with a high resolution,can make the printing patterns more realistic and true.
| Specifications | |||
| Model | DG-2513A | ||
| Print size | 2500*1300mm | ||
| Print head | EPSON i3200 | ||
| Print drops | 3.8PL | ||
| Print speed | 4pass Draft mode | 16.4㎡/h | |
| 6pass Production mode | 10.8㎡/h | ||
| 8pass High resolution mode | 7.9㎡/h | ||
| Color | C / M / Y / K / LC / LM / W / V | ||
| Print height | 100mm | ||
| Curing system | LED UV light | ||
| Image format | TIFF / BMP / EPS / JPEG | ||
| Cleaning system | Auto prositive press cleaning | ||
| Data interface | USB3.0 | ||
| Operation software | Windows7/10 X 64 | ||
| Power requirement | AC220 ，50Hz | ||
| Environment | Temperature | 20℃ - 30℃ | |
| Humidity | 30% - 70% | ||
| Dust | Similar to office environment | ||
| Machine size | 4333*2088*1300 | ||
| Certification | CE / ROHS / SGS | ||
| Net weight | 1000KG | ||
